GPU Engine Specs

CUDA Cores

4864

Boost Clock (MHz)

1680

Base Clock (MHz)

1410

Thermal and Power Spec

Minimum System Power Requirement (W)

650

Supplementary Power Connectors

8-pin

Memory Specs

Memory Clock

14Gbps

Standard Memory Config

8GB

Memory Interface

GDDR6

Memory Interface Width

256-bit

Memory Bandwidth (GB/sec)

448

Feature Support

Real-Time Ray Tracing

Yes

Ray Tracing Cores

2nd Generation

Tensor Cores

3rd Generation

NVIDIA Architecture

Ampere

Microsoft DirectX

12 Ultimate

NVIDIA DLSS

Yes

PCI Express Gen 4

Yes

NVIDIA GeForce Experience

Yes

NVIDIA Ansel

Yes

NVIDIA FreeStyle

Yes

Bus Support

PCI-E 4.0 X16

NVIDIA ShadowPlay

Yes

OS Certification

Windows 10, Linux, FreeBSDx86

NVIDIA Highlights

Yes

NVIDIA G-SYNC™-Ready

Yes

Game Ready Drivers

Yes

NVIDIA Studio Drivers

Yes

NVIDIA GPU Boost™

Yes

Vulkan API

Yes

OpenGL

4.6

DisplayPort 1.4a

Yes

NVIDIA Encoder

7th Generation

NVIDIA Decoder

5th Generation

HDMI 2.1a

Yes

LHR

This GeForce RTX 3060 Ti graphics card with LHR (lite hash rate) delivers 25 MH/s ETH hash rate (est.).

Accessories

Installation Guide

Yes

Power Guide

Yes

Graphics Card Stand

-

Graphics Card Dimensions

Length

240mm

Height

120mm

Width

2-slot

Display Support

Multi Monitor

Yes

Maxmium Digital Resolution

7680x4320

HDCP

2.3

Standard Display Connectors

HDMI 2.1, 3x DisplayPort 1.4a
