Specifications

Capacity

1TB

Form Factor

M.2 2280

Connector

M.2

Sequential Read Performance

5150MB/s

Sequential Write Performance

4900MB/s

Random Read

730K IOPS

Random Write

770K IOPS

Interface

PCIe Gen4 x4

Endurance (TBW)

600

Dimensions (L x W x H)

3.16" x 0.87" x 0.09"

Weight

5.7gms

Model Number

WDS100T4B0E

Operating Temperature

0°C to 85°C

Non-Operating Temperature

-40°C to 85°C

Certifications

BSMI, CAN ICES-3(B)/NMB-3(B), CE, FCC, KCC, Morocco, RCM, TUV, UL, VCCI

Product Features

• Harness AI and streamline your workflow with the combined power of PCIe® Gen 4 and Western Digital nCache™ 4.0
• Switch smoothly between applications and projects with high-end NVMe™ storage technology
• Create confidently with heavy-duty endurance for ideating, drafting, and finalizing your creative work

Compatibility

• Requires M.2 2280 port
• Compatibility may vary depending on user’s hardware configuration and operating system
