Interface

SATA 6.0Gb/s

Form Factor

2.5-inch internal SSD

Total Capacity

256GB

NAND

NAND Flash

External DDR Cache

N/A

Sequential Read speed

Up to 520 MB/s

Sequential Write speed

Up to 500 MB/s

Random Read IOPS

up to 80k

Random Write IOPS

up to 85k

Dimension

69.85 x 7 x 100 mm

Mean time between failure (MTBF)

2M hours

Power Consumption (Active)

Average : R : 2240mW ; W : 2610mW

Power Consumption (Idle)

170mW

Temperature (Operating)

0°C to 70°C

Temperature (Storage)

-40°C to 85°C

Note

• Test system configuration: configuration may vary by models; we will choose the latest platform for verification.
• Performance may vary based on SSD's firmware version and system hardware & configuration. Sequential performance measurements based on CrystalDiskMark and IOmeter 1.1.0.
• Speeds based on internal testing. Actual performance may vary.
• 1GB = 1 billion bytes. Actual useable capacity may vary.
