Model

MPE-7501-ACABW-3B

ATX Version

ATX 12V Ver. 3.1

PFC

Active PFC

Input Voltage

200-240Vac

Input Current

6A

Input Frequency

50-60Hz

Dimensions (L x W x H)

140 x 150 x 86 mm / 5.5 x 5.9 x 3.4 inch

Fan Size

120mm

Fan Bearing

HDB

Efficiency

>88% @ Typical Load

80 PLUS Rating

80 PLUS Bronze EU 230V

ErP 2014 Lot 3

Yes

Operating Temperature

0-40°C

Power Good Signal

100 - 150 ms

Hold Up Time

>16ms

MTBF

>100,000 Hours

Protections

UVP / OVP / OPP / OTP / SCP

Regulatory

TUV, CE, FCC, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (based on region's request.)

ATX 24 Pin Connectors

1

EPS 8 Pin / 4+4 Pin Connectors

2

SATA Connectors

6

Peripheral 4 Pin Connectors

3

PCI-e 6+2 Pin Connectors

4

Series

MWE Bronze Series

Category

500 to 750W

Modular

Non Modular

80 Plus Efficiency

Bronze

Form Factor

ATX

Watts

750W
