General Specifications

Name

AMD Ryzen™ 7 8700F

Family

Ryzen

Series

Ryzen 8000 Series

Form Factor

Desktops

AMD PRO Technologies

No

Consumer Use

Yes

Regional Availability

Global

Former Codename

“Phoenix”

Architecture

“Zen 4”

# of CPU Cores

8

Multithreading (SMT)

Yes

# of Threads

16

Max. Boost Clock

Up to 5GHz

Base Clock

4.1GHz

L2 Cache

8MB

L3 Cache

16MB

Default TDP

65W

AMD Configurable TDP (cTDP)

45-65W

Processor Technology for CPU Cores

TSMC 4nm FinFET

CPU Compute Die (CCD) Size

178mm²

Package Die Count

1

Unlocked for Overclocking

Yes

AMD EXPO™ Memory Overclocking Technology

Yes

Precision Boost Overdrive

Yes

Curve Optimizer Voltage Offsets

Yes

AMD Ryzen™ Master Support

Yes

CPU Socket

AM5

CPU Boost Technology

Precision Boost 2

Instruction Set

x86-64

Supported Extensions

AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64

Thermal Solution (PIB)

Wraith Spire Cooler

Max. Operating Temperature (Tjmax)

95°C

Launch Date

04/01/2024

*OS Support

Windows 11 – 64-Bit Edition
Windows 10 – 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.

Connectivity

Native USB 4 (40Gbps) Ports

2

Native USB 3.2 Gen 2 (10Gbps) Ports

2

Native USB 2.0 (480Mbps) Ports

1

PCI Express® Version

PCIe® 4.0

Native PCIe® Lanes (Total/Usable)

20 / 16

NVMe Support

Boot, RAID0, RAID1

System Memory Type

DDR5

Memory Channels

2

Max. Memory

256GB

System Memory Subtype

UDIMM

Max Memory Speed

2x1R     DDR5-5200
2x2R     DDR5-5200
4x1R     DDR5-3600
4x2R     DDR5-3600

Graphics Capabilities

Integrated Graphics

Discrete Graphics Card Required

AMD SmartAccess Memory

Yes

AI Engine Capabilities

Brand Name

AMD Ryzen™ AI

AMD Ryzen™ AI

Available

Performance

Up to 16 TOPS

Product IDs

Product ID Boxed

100-100001590BOX

Product ID Tray

100-000001590 (AM5)

Product ID MPK

100-100001590MPK

Security, Virtualization, and Manageability

AMD Enhanced Virus Protection (NX bit)

Yes
